Amateur Radio License Class

Spring, 2018

Northbrook Fire Department Rich Davidson, K9RD

Administration Building Education Director

740 Dundee Road (847) 295-8845 (home)

Northbrook, IL 60062 (847) 220-5771 (cell)

Classroom — lower level

Tuition: none

Preparation in all written elements required for Technician, General, and Extra Class Amateur Radio Licenses. Preparation also for GROL, MROP, Radiotelegraph Operator, GMDSS Operator and Maintainer, Ship Radar Endorsement commercial licenses. Preparation for Radio, Electronics, and Electricity merit badges for the Boy Scouts.

Text: The ARRL License Manual (Technician, General and Extra Classes)

Topics: Operating Procedures Electrical Principals Practical Circuits

Radio-Wave Propagation Circuits Components Signals And Emissions

Amateur Radio Practice Antennas and Feed Lines Question Pools

Wednesday, April 11, 2018, 7:00 PM to 9:00 PM - Electrical Principals

AC, DC, Pulse, Ohms Law, Safety, E, I, R, X, Z, P, Q, Phase Angle, RF, IF, AF

Wednesday, April 18, 2018, 7:00 PM to 9:00 PM - Practical Circuits and Electronic Components

Analog and Digital, Transmitters, Receivers, Filters, Power Supplies

Resistors, Capacitors, Inductors, Non-Linear and Active Devices

Wednesday, April 25, 2018, 7:00 PM to 9:00 PM - Instruments, Modulation, and Emissions

Oscilloscope, Spectrum Analyzer, Logic Probe, Techniques

Mixers and Detectors

AM, FM, PM, SSB, DSB, Pulse

Wednesday, May 2, 2018, 7:00 PM to 9:00 PM - Antennas and Propagation

Matching, Configurations, SWR, Transmission Lines

D, E, F Layers, Skip, MUF, Solar Flux, Scatter

Wednesday, May 9, 2018, 7:00 PM to 9:00 PM - Advanced Topics

Smith Charts, AMSAT, Complex Impedance, ATV, SSTV, FAX, Digital Modes, EME,

Meteor Burst, Direction Finding, Opto Electronics, Receiver Design Principals, Mobile

Wednesday, May 16, 2018, 7:00 PM to 9:00 PM – Problem Sets

Wednesday, May 23, 2018, 7:00 PM to 9:00 PM – Problem Sets

Wednesday, May 30, 2018, 7:00 PM to 9:00 PM – Testing administered by the ARRL/VEC program

Testing fee $15.00, established by the VEC, session is open to the public, location same as classes.

Test candidates must bring photo ID and copy of current license



Our club member, Casey, KV3T has established a schedule for what our club is calling “ Ham-in-the Park”.  His plan is established below.  In his own words, he states:

“In 2018, I plan to get out portable once a month.  I’ve gone through the year and picked out some dates that will work for my personal schedule and have posted them below.  Last year I found that Saturday afternoons at 1pm worked really well for me (with a little one at home, that is just before nap time, and I can get home before dinner).

As a reminder, this isn’t a ‘formal club event’ so the support is limited to none.  But for me that is the entire appeal.  You can come and play with whatever you have and want to play with, and be surrounded with other like minded hams who…. know more about your stuff than you do.  (I’m still trying to figure out how to property adjust SSB mic gain).  However, that said, you don’t need to bring a radio to come and hang out.  This could, in fact, be a great opportunity to come out and get on HF if you have never done so before.  You can use my radio, if you don’t have or want to bring your own.  I think of this as the sort of the opposite of field day.  A chance to get out and use your own gear, in your own way, and make some mistakes that you can learn from.  Practice getting lines into trees, figure out how to use your solar panel or field portable antennas, or from personal experience learn why a 75’ throw line isn’t long enough, and where not to set up a solar panel (behind your easy-up as the sun sets).

The dates I have chosen are:

3/31  -  Details below



(end of June omitted due to field day)





All of these I plan to start around 1pm (sometimes I’m late, but I’m for sure coming unless something major comes up, in which case I’ll post back here.)

Of course, this is weather dependent, we aren’t going to go out in a lightning storm.

So, for the first one, I think  we will revisit the location where I did the first one of these last year.  It is a somewhat secluded park in Glenview with some very tall trees and any great opportunities to practice and play with antennas.  And at this location, there isn’t much public around, so there is no one to hit with a throw bag, or people to clothesline with an antenna.

Who:  Myself and anyone else who wants to plan radio

What:  Playing with Radios in the Field

When: Saturday March 31, 2018.  1pm until you want to leave (for sure done by 6pm)

Where:  42.07941,-87.80320  Roughly 1323 Pine Street, Glenview, IL

Note that google maps still shows this as populated with houses.  It is not, there is a park here.  I promise.

I also plan to be beaconing APRS from this location, if you are so equipped.  Look for KV3T-9

Feel free to RSVP (if you want, no need) or ask questions.  Feel free to just come and hang out and have some fun!”
